Description
Product Specifications
| Shank diameter | 200 |
| Needle size Asia | 19 |
| Length butt to eye | 339 |
| Coating | Chromium |
| Needle form | A |
| Needle form description | A1 |
| Canu point | LL CR |
| Canu designation | 20:05 |
| Catalog designation | 339200AC04LL |
| Technical sewing application | Double lock stitch |
| Stitch type class | 300 |
| Special(s) | Point groove right |
| Recommended for | Thick leather |
| Examples of use | Car seats |
| Needle size | 120 |
| Point style | LL |
| Needle system | 134 |
| Needle system family | 134 |
| Sorting number | 719980 |
| Pack standard | N-S-00017 |
| Customary needle designations | PFX134 LL |
| System designation 2 | MTX134 LL |
| System designation 3 | TFX2 |
| System designation 4 | 16X2 TW |
| System designation 5 | 16X74 TW |
| System designation 6 | 134 LL |
| System designation 7 | 135X8 TW |
| System designation 8 | 797 LL |
| System designation 9 | SY 6811 |
| System designation 10 | 16X2 TW |
| System designation 11 | 16X74 TW |
| System designation 12 | 16X230 TW |
| System designation 13 | 563 LL |
| System designation 14 | 1738 LL |
| System designation 15 | 134 KK LL |
| Seam | Decorative seam |
| Needle recommendation | Quality choice |
Point Style
Cutting point• Cuts the leather in the sewing direction at an angle of 45°, slanted to the left
• Very straight seam position
• Thread slightly elevated
• Stitch holes largely filled
• Suitable for short to medium stitches
• Very straight seam position
• Thread slightly elevated
• Stitch holes largely filled
• Suitable for short to medium stitches
