Description
Product Specifications
| Shank diameter | 200 |
| Needle size Asia | 16 |
| Length butt to eye | 339 |
| Coating | Chromium |
| Needle form | A |
| Needle form description | A1 |
| Canu point | P |
| Canu designation | 20:05 |
| Catalog designation | 339200AC01P |
| Further point designations | NW |
| Further point designations 02 | PS |
| Further point designations 03 | SP |
| Further point designations 04 | V |
| Further point designations 05 | W |
| Technical sewing application | Double lock stitch |
| Stitch type class | 300 |
| Recommended for | Thin leather |
| Examples of use | Leather clothing |
| Needle size | 100 |
| Point style | P |
| Needle system | 134 |
| Needle system family | 134 |
| Sorting number | 721900 |
| Pack standard | N-S-00017 |
| Customary needle designations | PFX134 P |
| System designation 2 | 134 PS |
| System designation 3 | 135X6 NW |
| System designation 4 | 135X6 W |
| System designation 5 | 135X8 NW |
| System designation 6 | 135X8 W |
| System designation 7 | 797 P |
| System designation 8 | 797 PS |
Point Style
Cutting Point• Cuts the leather perpendicular to the sewing direction at an angle of 90°
• Creates a prominent decorative effect on thick and hard leather due to the slanted thread position
• Thread very deep-set
• Stitch holes largely filled by the thread
• Suitable for very short stitches
• Creates a prominent decorative effect on thick and hard leather due to the slanted thread position
• Thread very deep-set
• Stitch holes largely filled by the thread
• Suitable for very short stitches
