Description
Product Specifications
| Shank diameter | 163 |
| Needle size Asia | 18 |
| Length butt to eye | 339 |
| Coating | Chromium |
| Needle form | A |
| Needle form description | A1 |
| Canu point | LR |
| Canu designation | 14:25 |
| Catalog designation | 339163AC01LR |
| Further point designations | NRTW |
| Further point designations 02 | RTW |
| Technical sewing application | Double lock stitch |
| Stitch type class | 300 |
| Recommended for | Thin leather |
| Examples of use | Leather clothing |
| Needle size | 110 |
| Point style | LR |
| Needle system | 1738 |
| Needle system family | 1738 |
| Sorting number | 755420 |
| Pack standard | N-S-00017 |
| Customary needle designations | DB X F2 |
| System designation 2 | 16X230 RTW |
| System designation 3 | 16X257 LR |
| System designation 4 | 287 WH LR |
| System designation 5 | 1738 A LR |
| System designation 6 | 1738 LR |
Point Style
Cutting point• Cuts the leather in the sewing direction at an angle of 45°, slanted to the right
• Thread: slight to moderate slant (leatherdependent), slightly elevated
• Stitch holes easily visible
• Suitable for short to medium stitches
• Thread: slight to moderate slant (leatherdependent), slightly elevated
• Stitch holes easily visible
• Suitable for short to medium stitches
