Description
Product Specifications
| Shank diameter | 163 |
| Needle size Asia | 21 |
| Length butt to eye | 339 |
| Coating | Chromium |
| Needle form | A |
| Needle form description | A1 |
| Canu point | LR |
| Canu designation | 11:45 |
| Catalog designation | 339163AC03LR |
| Further point designations | NRTW |
| Further point designations 02 | RTW |
| Technical sewing application | Double lock stitch |
| Stitch type class | 300 |
| Recommended for | Thick leather |
| Examples of use | Car seats |
| Needle size | 130 |
| Point style | LR |
| Needle system | 287 |
| Needle system family | 287 |
| Sorting number | 742280 |
| Pack standard | N-S-00017 |
| Customary needle designations | TFX 287 LR |
| System designation 2 | 130 B LR |
| System designation 3 | 287 H LR |
| System designation 4 | 287 L |
| System designation 5 | 287 LR |
| System designation 6 | 376 LR |
| System designation 7 | 606 LR |
| System designation 8 | 690 LR |
| System designation 9 | SY6632 |
Point Style
Cutting point• Cuts the leather in the sewing direction at an angle of 45°, slanted to the right
• Thread: slight to moderate slant (leatherdependent), slightly elevated
• Stitch holes easily visible
• Suitable for short to medium stitches
• Thread: slight to moderate slant (leatherdependent), slightly elevated
• Stitch holes easily visible
• Suitable for short to medium stitches
