Description
Product Specifications
| Shank diameter | 250 |
| Needle size Asia | 24 |
| Length butt to eye | 520 |
| Coating | Chromium |
| Needle form | A |
| Needle form description | A1 |
| Canu point | S |
| Canu designation | 50:10 |
| Catalog designation | 520230AC01S |
| Further point designations | CR |
| Further point designations 02 | RSP |
| Further point designations 03 | NCR |
| Technical sewing application | Double lock stitch |
| Stitch type class | 300 |
| Recommended for | Thick leather |
| Examples of use | Car seats |
| Needle size | 180 |
| Point style | S |
| Needle system | 328 |
| Needle system family | 328 |
| Sorting number | 743780 |
| Pack standard | N-S-00870 |
| Customary needle designations | DDX2 S |
| System designation 2 | KRX3 |
| System designation 3 | 214X2 NCR |
| System designation 4 | 328 S |
| System designation 5 | SY 4968 |
Point Style
Cutting point• Cuts the leather in the sewing direction
• Straight seam
• Tight stitch formation with corresponding leather and stitch size
• Stitch holes are elongated and clearly visible in the seam
• Suitable for medium to large stitches
• Straight seam
• Tight stitch formation with corresponding leather and stitch size
• Stitch holes are elongated and clearly visible in the seam
• Suitable for medium to large stitches
