Description
Product Specifications
| Shank diameter | 163 |
| Needle size Asia | 18 |
| Length butt to eye | 339 |
| Coating | Chromium |
| Needle form | A |
| Needle form description | A1 |
| Canu point | P CL |
| Canu designation | 12:05 |
| Catalog designation | 339163AC09P |
| Further point designations | NWLT |
| Technical sewing application | Double lock stitch |
| Stitch type class | 300 |
| Special(s) | Point groove left |
| Recommended for | Thin leather |
| Examples of use | Leather clothing |
| Needle size | 110 |
| Point style | PCL |
| Needle system | 34 |
| Needle system family | 34 |
| Sorting number | 694740 |
| Pack standard | N-S-00017 |
| Customary needle designations | TFX4 |
| System designation 2 | 16X4 |
| System designation 3 | 16X4 NW |
| System designation 4 | 16X246 NW |
| System designation 5 | 287 PCL |
| System designation 6 | 287 PCL |
| System designation 7 | 376 PCL |
| System designation 8 | 973 PCL |
Point Style
Cutting Point• With a point groove
• Cuts the leather perpendicular to the sewing direction at an angle of 90°
• Creates a prominent decorative effect on thick and hard leather due to the slanted thread position
• Thread very deep-set
• Stitch holes largely filled by the thread
• Suitable for very short stitches
• Cuts the leather perpendicular to the sewing direction at an angle of 90°
• Creates a prominent decorative effect on thick and hard leather due to the slanted thread position
• Thread very deep-set
• Stitch holes largely filled by the thread
• Suitable for very short stitches
