Description
Product Specifications
| Shank diameter | 200 |
| Needle size Asia | 11 |
| Length butt to eye | 339 |
| Coating | Chromium |
| Needle form | A |
| Needle form description | A1 |
| Canu point | SD1 |
| Canu designation | 20:05 |
| Catalog designation | 339200AC01SD |
| Further point designations | R-TRI |
| Further point designations 02 | SD 1 |
| Further point designations 03 | TRI FACET |
| Further point designations 04 | TRI TIP |
| Technical sewing application | Double lock stitch |
| Stitch type class | 300 |
| Recommended for | Thin leather |
| Examples of use | Fine leather goods |
| Needle size | 75 |
| Point style | SD |
| Needle system | 134 |
| Needle system family | 134 |
| Sorting number | 724340 |
| Pack standard | N-S-00017 |
| Customary needle designations | DPX5 |
| System designation 2 | DPX7 |
| System designation 3 | DPX134 |
| System designation 4 | PFX134 |
| System designation 5 | MTX797 |
| System designation 6 | 135X5 |
| System designation 7 | 135X7 |
| System designation 8 | 797 |
| System designation 9 | 1844 |
| System designation 10 | SY 1901 |
| System designation 11 | SY 1955 |
Point Style
Round point with polished triple cutting edges at the very end of the point• Slightly triangular cut in leather
• Straight seam
• Thread slightly elevated
• Suitable for short to medium stitches
• Straight seam
• Thread slightly elevated
• Suitable for short to medium stitches
