Description
Product Specifications
| Shank diameter | 163 |
| Needle size Asia | 22 |
| Length butt to eye | 339 |
| Coating | Chromium |
| Needle form | A |
| Needle form description | A1 |
| Canu point | R |
| Canu designation | 14:20 |
| Catalog designation | 339163AC12R |
| Further point designations | SET |
| Further point designations 02 | RD |
| Technical sewing application | Double lock stitch |
| Stitch type class | 300 |
| Recommended for | Medium-weight to heavy woven fabrics |
| Examples of use | Jeans >14 oz |
| Needle size | 140 |
| Point style | R |
| Needle system | 1738A |
| Needle system family | 1738 |
| Needle system variant | A |
| Sorting number | 754040 |
| Pack standard | N-S-00017 |
| Customary needle designations | DLX1 |
| System designation 2 | 16X85 |
| System designation 3 | 16X95 |
| System designation 4 | 71X1 |
| System designation 5 | DBX95 |
| System designation 6 | DLX95 |
| System designation 7 | 287 WH |
| System designation 8 | 431 |
| System designation 9 | 1442 |
| System designation 10 | SY 1513 |
| System designation 11 | SY 1515 |
| System designation 12 | SY 1526 |
| System designation 13 | 1738 A |
| System designation 14 | 1738 AK |
Point Style
Normal round point• Slightly sharp point
• Suitable for woven fabrics, coated materials, soft clothing leather and artificial leather
• Standard point for lockstitch
• Suitable for woven fabrics, coated materials, soft clothing leather and artificial leather
• Standard point for lockstitch
