Description
Product Specifications
| Shank diameter | 163 |
| Needle size Asia | 8 |
| Length butt to eye | 339 |
| Coating | Chromium |
| Needle form | A |
| Needle form description | A1 |
| Canu point | SES |
| Special application needle | SAN10XS |
| Canu designation | 14:26 |
| Catalog designation | 339163AC36FFG |
| Further point designations | SES |
| Further point designations 02 | L BALL |
| Further point designations 03 | J BALL |
| Further point designations 04 | SIN |
| Further point designations 05 | NYR |
| Further point designations 06 | BPL |
| Further point designations 07 | TB |
| Further point designations 08 | B |
| Further point designations 09 | R K |
| Technical sewing application | Double lock stitch |
| Stitch type class | 300 |
| Recommended for | Finest knitwear and finest woven fabrics, extremely delicate and with very critical sewability |
| Examples of use | Underwear |
| Needle size | 60 |
| Point style | FFG |
| Needle system | DBX1 SAN 10 XS |
| Needle system family | DBX1 |
| Needle system variant | SAN 10 XS |
| Sorting number | 683560 |
| Pack standard | N-S-00017 |
| Customary needle designations | 1738 SAN 10 XS |
| System designation 2 | 16X257 SAN 10 XS |
| System designation 3 | 16X231 SAN 10 XS |
| System designation 4 | DBX1 SAN 10XS |
| System designation 5 | DBX1 SF |
| System designation 6 | DBX1 KN |
Point Style
Small ball point• Round point with small ball
• Suitable for fine and medium-weight knitted and woven fabrics
• When penetrating the material, the small ball point displaces the loops so that the material doesn‘t get damaged
• Perfectly suited for jersey and tricot fabrics
• Suitable for fine and medium-weight knitted and woven fabrics
• When penetrating the material, the small ball point displaces the loops so that the material doesn‘t get damaged
• Perfectly suited for jersey and tricot fabrics
