Description
Product Specifications
| Shank diameter | 200 |
| Needle size Asia | 9 |
| Length butt to eye | 339 |
| Coating | Chromium |
| Needle form | A |
| Needle form description | A1 |
| Canu point | S |
| Canu designation | 18:60 |
| Catalog designation | 339200AC02RS |
| Further point designations | CR |
| Further point designations 02 | RSP |
| Further point designations 03 | NCR |
| Technical sewing application | Double lock stitch |
| Stitch type class | 300 |
| Special(s) | Short shank |
| Recommended for | Thin leather |
| Examples of use | Leather clothing |
| Needle size | 65 |
| Point style | S |
| Needle system | 134 KK |
| Needle system family | 134 |
| Needle system variant | KK |
| Sorting number | 719300 |
| Pack standard | N-S-00017 |
| Customary needle designations | DPXF19 |
| System designation 2 | DPXF22 |
| System designation 3 | 134 KK SS |
| System designation 4 | 797 KK S |
| System designation 5 | 797 KK SS |
| System designation 6 | SY 6758 |
Point Style
Cutting point• Cuts the leather in the sewing direction
• Straight seam
• Tight stitch formation with corresponding leather and stitch size
• Stitch holes are elongated and clearly visible in the seam
• Suitable for medium to large stitches
• Straight seam
• Tight stitch formation with corresponding leather and stitch size
• Stitch holes are elongated and clearly visible in the seam
• Suitable for medium to large stitches
